ASAHI Halberd®

Device-Type

Mandril/Specialty Guidewires

Targated Speciality

Endovascular

Manufacturer

ASAHI Gaia technology

ASAHI Halberd® 0.014 inch

Superior directional control with excellent torque transmission and high penetration.


ASAHI Halberd® 0.018 inch

Balanced power to cross highly stenosed lesions.


This product is intended to facilitate the placement and exchange of diagnostic and therapeutic devices during intravascular procedures. This device is intended for peripheral vascular use only.

Features and Benefits

ASAHI Halberd® 0.014 inch

  • TIP LOAD - 12gf
  • TIP RADIOPACITY - 55 cm
  • COATING - HYDROPHILIC WITH UNCOATED DISTAL TIP. Coated with SLIP-COAT® coating


ASAHI Halberd® 0.018 inch

  • TIP LOAD - 12gf
  • TIP RADIOPACITY - 11 cm
  • COATING - HYDROPHILIC* WITH UNCOATED DISTAL TIP. Coated with SLIP-COAT® coating


Related Device SKUs

* Select 2 or more (upto 4) SKUs to compare.
SKU Name Device SKUs Model TIP SHAPE LENGTH (CM) DIAMETER (INCH(MM)) RADIOPAQUE SEGMENT (CM) SPRING COIL (CM)
ASAHI Halber .014"
ASAHI Halber .014"
 		PHW14R101S Straight 200 0.014(0.36) 5 5
ASAHI Halberd .014"
ASAHI Halberd .014"
 		PHW14R301S Straight 300 0.014(0.36) 5 5
ASAHI Halberd .018"
ASAHI Halberd .018"
 		PHW18R101S Straight 200 0.018(0.45) 11 11
ASAHI Halberd .018"
ASAHI Halberd .018"
 		PHW18R301S Straight 300 0.018(0.45) 11 11
device-thumbnail
ASAHI Halber .014"
  • Model : PHW14R101S
  • Procedure : -
  • TIP SHAPE : Straight
  • LENGTH (CM) : 200
  • DIAMETER (INCH(MM)) : 0.014(0.36)
  • RADIOPAQUE SEGMENT (CM) : 5
  • SPRING COIL (CM) : 5
device-thumbnail
ASAHI Halberd .014"
  • Model : PHW14R301S
  • Procedure : -
  • TIP SHAPE : Straight
  • LENGTH (CM) : 300
  • DIAMETER (INCH(MM)) : 0.014(0.36)
  • RADIOPAQUE SEGMENT (CM) : 5
  • SPRING COIL (CM) : 5
device-thumbnail
ASAHI Halberd .018"
  • Model : PHW18R101S
  • Procedure : -
  • TIP SHAPE : Straight
  • LENGTH (CM) : 200
  • DIAMETER (INCH(MM)) : 0.018(0.45)
  • RADIOPAQUE SEGMENT (CM) : 11
  • SPRING COIL (CM) : 11
device-thumbnail
ASAHI Halberd .018"
  • Model : PHW18R301S
  • Procedure : -
  • TIP SHAPE : Straight
  • LENGTH (CM) : 300
  • DIAMETER (INCH(MM)) : 0.018(0.45)
  • RADIOPAQUE SEGMENT (CM) : 11
  • SPRING COIL (CM) : 11
