OPTA® PRO PTA Dilatation Catheter

Device-Type

PTA Ballons

Manufacturer

Cordis


The everyday choice for efficient renal and leg interventions.

Features and Benefits

  • 035” PTA Balloon
  • Outstanding delivery through a 6F sheath introducer (select sizes)
  • 5F dual-lumen shaft
  • Optimal-rated burst pressure: 10atm (3mm-10mm) and 6atm
  • Flexible, tapered tip


Safety informations

Indications

The OPTA® PRO PTA catheter is intended to dilate stenoses in iliac, femoral, ilio-femoral, popliteal, infra popliteal and renal arteries and for the treatment of obstructive lesions of native or synthetic arteriovenous dialysis fistulae.


Contraindications

None known for PTA procedure. The OPTA® PRO PTA catheter is contraindicated for use in coronary arteries.


Warnings

  • This device is intended for one time use only. DO NOT resterilize and/or reuse it, as this can potentially result in compromised device performance and increased risk of inappropriate resterilization and cross contamination.
  • To reduce the potential for vessel damage, the inflated diameter of the balloon should approximate the diameter of the vessel just proximal and distal to the stenosis.
  • When the catheter is exposed to the vascular system, it should be manipulated while under high-quality fluoroscopic observation.
  • Do not advance or retract the catheter unless the balloon is fully deflated.
  • If resistance is met during manipulation, determine the cause of the resistance before proceeding.
  • Balloon pressure should not exceed the rated burst pressure. The rated burst pressure is based on the results of in-vitro testing. At least 99.9% of the balloons (with a 95% confidence), will not burst at or below their rated burst pressure. Use of a pressure monitoring device is recommended to prevent over pressurization. Use only the recommended balloon inflation medium.
  • Never use air or any gaseous medium to inflate the balloon.
  • Use the catheter prior to the “Use By” date specified on the package.


Precautions

  • Prior to angioplasty, the catheter should be examined to verify functionality and ensure that its size and shape are suitable for the specific procedure for which it is to be used.
  • The catheter system should be used only by physicians trained in the performance of arteriography and who have received appropriate training in percutaneous transluminal angioplasty.
  • Consider the use of systemic heparinization. Flush all devices entering the vascular system with sterile heparinized saline or similar isotonic solution.
  • The minimal acceptable sheath French size is printed on the package label. Do not attempt to pass the PTA catheter through a smaller size sheath introducer than indicated on the label.
  • Not intended for precise arterial blood pressure monitoring.

Potential adverse events

Possible adverse effects include, but are not limited to, the following:

  • Air embolism
  • Aneurysm
  • Hematoma at the puncture site
  • Perforation of the vessel wall.

Device Documents

Related Device SKUs

* Select 2 or more (upto 4) SKUs to compare.
SKU Name Device SKUs Model Balloon Diamter(mm) Balloon Length(mm) Rated Burst Pressure(atm) Sheath Fit(f) Shaft Length(cm)
OPTA® Pro PTA Dilatation Catheter
4193040S 3 40 10 5 80
OPTA® Pro PTA Dilatation Catheter
4194020S 4 20 10 5 80
OPTA® Pro PTA Dilatation Catheter
4194040S 4 40 10 5 80
OPTA® Pro PTA Dilatation Catheter
4194080S 4 80 10 5 80
OPTA® Pro PTA Dilatation Catheter
4194000S 4 100 10 5 80
OPTA® Pro PTA Dilatation Catheter
4195020S 5 20 10 5 80
OPTA® Pro PTA Dilatation Catheter
4195030S 5 30 10 5 80
OPTA® Pro PTA Dilatation Catheter
4195040S 5 40 10 5 80
OPTA® Pro PTA Dilatation Catheter
4195000S 5 100 10 5 80
OPTA® Pro PTA Dilatation Catheter
4196020S 6 20 10 5 80
OPTA® Pro PTA Dilatation Catheter
4196040S 6 40 10 5 80
OPTA® Pro PTA Dilatation Catheter
4197020S 7 20 10 5 80
OPTA® Pro PTA Dilatation Catheter
4197030S 7 30 10 5 80
OPTA® Pro PTA Dilatation Catheter
4193040L 3 40 10 5 110
OPTA® Pro PTA Dilatation Catheter
4193080L 3 80 10 5 110
OPTA® Pro PTA Dilatation Catheter
4194080L 4 80 10 5 110
OPTA® Pro PTA Dilatation Catheter
4194000L 4 100 10 5 110
OPTA® Pro PTA Dilatation Catheter
4195000L 5 100 10 5 110
OPTA® Pro PTA Dilatation Catheter
4196020L 6 20 10 5 110
OPTA® Pro PTA Dilatation Catheter
4196040L 6 40 10 5 110
OPTA® Pro PTA Dilatation Catheter
4196060L 6 60 10 5 110
OPTA® Pro PTA Dilatation Catheter
4196080L 6 80 10 6 110
OPTA® Pro PTA Dilatation Catheter
4196000L 6 100 10 6 110
OPTA® Pro PTA Dilatation Catheter
4197020L 7 20 10 5 110
OPTA® Pro PTA Dilatation Catheter
4193080X 3 80 10 5 135
OPTA® Pro PTA Dilatation Catheter
4194020X 4 20 10 5 135
OPTA® Pro PTA Dilatation Catheter
4195040X 5 40 10 5 135
OPTA® Pro PTA Dilatation Catheter
4196040X 6 40 10 5 135
OPTA® Pro PTA Dilatation Catheter
4197040S 7 40 10 5 80
OPTA® Pro PTA Dilatation Catheter
4197060S 7 60 10 6 80
OPTA® Pro PTA Dilatation Catheter
4197000S 7 100 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198020S 8 20 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198030S 8 30 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198040S 8 40 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198060S 8 60 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198080S 8 80 10 6 80
OPTA® Pro PTA Dilatation Catheter
4198000S 8 100 10 6 80
OPTA® Pro PTA Dilatation Catheter
4199020S 9 20 10 6 80
OPTA® Pro PTA Dilatation Catheter
4199040S 9 40 10 6 80
OPTA® Pro PTA Dilatation Catheter
4190020S 10 20 10 6 80
OPTA® Pro PTA Dilatation Catheter
4190030S 10 30 10 6 80
OPTA® Pro PTA Dilatation Catheter
4190040S 10 40 10 6 80
OPTA® Pro PTA Dilatation Catheter
4190060S 10 60 10 7 80
OPTA® Pro PTA Dilatation Catheter
4192020S 12 20 6 7 80
OPTA® Pro PTA Dilatation Catheter
4192030S 12 30 6 7 80
OPTA® Pro PTA Dilatation Catheter
4192040S 12 40 6 7 80
OPTA® Pro PTA Dilatation Catheter
4197040L 7 40 10 5 110
OPTA® Pro PTA Dilatation Catheter
4197060L 7 60 10 6 110
OPTA® Pro PTA Dilatation Catheter
4197080L 7 80 10 6 110
OPTA® Pro PTA Dilatation Catheter
4198020L 8 20 10 6 110
OPTA® Pro PTA Dilatation Catheter
4198040L 8 40 10 6 110
OPTA® Pro PTA Dilatation Catheter
4198080L 8 80 10 6 110
OPTA® Pro PTA Dilatation Catheter
4199020L 9 20 10 6 110
OPTA® Pro PTA Dilatation Catheter
4190020L 10 20 10 6 110
OPTA® Pro PTA Dilatation Catheter
4190040L 10 60 10 7 110
OPTA® Pro PTA Dilatation Catheter
4192020L 12 20 6 7 110
OPTA® Pro PTA Dilatation Catheter
4192040L 12 40 6 7 110
OPTA® Pro PTA Dilatation Catheter
4190040X 10 40 10 6 135
  • Model : 4193040S
  • Procedure : -
  • Balloon Diamter(mm) : 3
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4194020S
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4194040S
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4194080S
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4194000S
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4195020S
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4195030S
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 30
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4195040S
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4195000S
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4196020S
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4196040S
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4197020S
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4197030S
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 30
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4193040L
  • Procedure : -
  • Balloon Diamter(mm) : 3
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4193080L
  • Procedure : -
  • Balloon Diamter(mm) : 3
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4194080L
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4194000L
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4195000L
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4196020L
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4196040L
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4196060L
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4196080L
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4196000L
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4197020L
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4193080X
  • Procedure : -
  • Balloon Diamter(mm) : 3
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 135
  • Model : 4194020X
  • Procedure : -
  • Balloon Diamter(mm) : 4
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 135
  • Model : 4195040X
  • Procedure : -
  • Balloon Diamter(mm) : 5
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 135
  • Model : 4196040X
  • Procedure : -
  • Balloon Diamter(mm) : 6
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 135
  • Model : 4197040S
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 80
  • Model : 4197060S
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4197000S
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198020S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198030S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 30
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198040S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198060S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198080S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4198000S
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 100
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4199020S
  • Procedure : -
  • Balloon Diamter(mm) : 9
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4199040S
  • Procedure : -
  • Balloon Diamter(mm) : 9
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4190020S
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4190030S
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 30
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4190040S
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 80
  • Model : 4190060S
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 80
  • Model : 4192020S
  • Procedure : -
  • Balloon Diamter(mm) : 12
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 6
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 80
  • Model : 4192030S
  • Procedure : -
  • Balloon Diamter(mm) : 12
  • Balloon Length(mm) : 30
  • Rated Burst Pressure(atm) : 6
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 80
  • Model : 4192040S
  • Procedure : -
  • Balloon Diamter(mm) : 12
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 6
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 80
  • Model : 4197040L
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 5
  • Shaft Length(cm) : 110
  • Model : 4197060L
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4197080L
  • Procedure : -
  • Balloon Diamter(mm) : 7
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4198020L
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4198040L
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4198080L
  • Procedure : -
  • Balloon Diamter(mm) : 8
  • Balloon Length(mm) : 80
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4199020L
  • Procedure : -
  • Balloon Diamter(mm) : 9
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4190020L
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 110
  • Model : 4190040L
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 60
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 110
  • Model : 4192020L
  • Procedure : -
  • Balloon Diamter(mm) : 12
  • Balloon Length(mm) : 20
  • Rated Burst Pressure(atm) : 6
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 110
  • Model : 4192040L
  • Procedure : -
  • Balloon Diamter(mm) : 12
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 6
  • Sheath Fit(f) : 7
  • Shaft Length(cm) : 110
  • Model : 4190040X
  • Procedure : -
  • Balloon Diamter(mm) : 10
  • Balloon Length(mm) : 40
  • Rated Burst Pressure(atm) : 10
  • Sheath Fit(f) : 6
  • Shaft Length(cm) : 135

Questions & Answers

Don't see the answer you're looking for ?
