Product Detail

Designed for Ease of Entry and Reduced Trauma

Smooth Transitions

• Smooth transitions facilitate ease of entry with lower insertion force
• Improved kink resistance and lubricity enhance pushability while maintaining device integrity
• Long, gradually tapered tip reduces potential for vessel trauma

Excellent Catheter Passage

• Silicone-coated valve and smooth inner surface promote device passage
• Tricuspid valve design promotes hemostasis

Ease of Use

• Innovative dilator/hub twist-lock for safety and security during insertion
• Translucent hub allows visibility
• Rotating suture wing allows for sheath securement

Device Highlights

• Sheaths are available in 7cm, 11cm and 25cm lengths with French sizes ranging from 4-9F. All sheaths are sold with dilators.
• Dilator lengths are 17cm (11cm sheath) and 31cm (25cm sheath).
• 11cm sheaths may be purchased with or without mini guide wires. Mini guide wire diameters are 0.035 inch (4-9F) and 0.038 inch (5-9F).

INDICATIONS

This device is indicated for use in the introduction of diagnostic and interventional devices inserted into the human vasculature.

CONTRAINDICATIONS

None known.

WARNING

NOTE: This product contains Di(2-ehylhexyl) phthalate (DEHP). Togo Medikit has conducted a Chemical Safety Assessment of DEHP in this device based on currently known acceptable exposure limits for sensitive populations (children and pregnant/nursing women), and has determined that the potential exposure is below the known acceptable exposure limits for the device when used in accordance with the indications and instructions for use.

PRECAUTION

This device is only to be used by a trained physician.

ADVERSE EVENTS

• Air embolism
• Infection
• Intimal tear
• Hemorrhage (hematoma or retroperitoneal bleed)
• Perforation of the vessel wall
• Thrombus formation
• vessel occlusion
• AV fistula
• Emboli
• Pseudoaneurysm
